TM-T70

Get the high performance and reliability you need and streamline your POS system with Epson’s space-saving TM-T70 thermal receipt printer. With its small size and low height (only 4.49" high), it's designed to fit under your counter or in other small spaces. And all the features operate entirely from the front of the printer for easy access and easy maintenance.



  • Features
  • Specifications
  • PDF

• Front-facing controls, paper loading and receipt dispensing

• Small, space-saving footprint

• Designed to fit under counters

• Fast and versatile printing up to 170mm per second

• Sealed top for superior spill resistance

• Ease-of-use features including drop-in paper loading, autocutter and status LEDs

• Low power consumption, ENERGY STAR® qualified

• Two-year warranty

Print method Thermal line printing
Print fonts 9 x 17 and 12 x 24 dots/character (W x H)
Column capacity Standard: Paper width 80mm: 48/64; Paper width 58mm: 35/46 42 Column Mode: Paper width 80mm: 42/60; Paper width 58mm: 42/31
Character size 0.88 × 2.13 and 1.25 × 3 mm (W x H)
Character set 95 Alphanumeric, 18 set International, 128 × 43 Graphic. Barcode: UPC-A, UPC-E, JAN13 (EAN13), JAN8 (EAN), CODE39, ITF, CODABAR (NW-7), CODE93, CODE128, GS1-128, GS1 DataBar. Two-dimensional code: PDF417, QRCode, MaxiCode, 2D GS1 DataBar, Composite Symbology
Characters per inch 22.6 and 16.9 cpi
Interface USB
Print speed Max. 150 mm/sec (5.91 in/sec)
Paper dimensions 80mm: 3.13” ± 0.02” x 3.27” diameter (79.5 ± 0.5(W) x 83mm) 58mm: 2.26” ± 0.02” x 3.27” diameter (57.5 ± 0.5(W) x 83mm)
Power 100 – 240V AC, 50/60 Hz
Power consumption Approx. 1.0A
Power supply Internal (AC cable included)
D.K.D. function 2 drivers
Autocutter 1.5 million cuts
Overall dimensions 5.51" x 7.83" x 5.75” (140 x 199 x 146 mm) (W x D x H)
Weight 3.75lb (1.7 kg)
Color Epson Dark Gray, Epson Cool White
Standard accessories Roll paper × 1 roll (for checking the initial movement of the printer), CD-ROM, power switch cover, power switch waterproof cover, wall hanging bracket, screws for wall hanging bracket, rubber feet for vertical installation, switch panel for vertical installation, 58mm width paper guide plate, interface cable, AC cable
Safety standards UL/CSA/EN/TUV/GOST-R
CD ROM contents Drivers & tool software (APD, OPOS™, JavaPOS™, OPOS NET™, TM Virtual port driver, Linux® Cups driver, Mac OS® X driver, ReadyPrint T20 Utility, EpsonNet Simple Viewer), Manuals (ReadyPrint T20 user‘s manual, ReadyPrint T20 software manual)
Installation Horizontal/vertical on counter/vertical on wall with wall hanging bracket
Warranty 2 year limited
